Vacuum Forming Machine LITE 1510
Sheet-Fed Thermoforming Machine
1 / 5
Description
LITE 1510 Vacuum Forming Machine — 1500 × 1000 mm The LITE 1510 is an industrial vacuum forming machine designed to manufacture three-dimensional plastic parts from thermoplastic sheets. Its robust construction and powerful heating system make it suitable for production facilities, engineering workshops, and custom manufacturing. Technical Specifications Sheet size: 1500 × 1000 mm Forming area: 1460 × 960 mm Maximum forming depth: 400 mm Maximum material thickness: 7 mm Power consumption: 40 kW Power supply: Three-phase, 400 V, 50 Hz. Key Features The machine features 450 W infrared quartz heaters, servo-driven movement of the heating unit, a pneumatically operated forming table, and a manually operated clamping frame. A 7-inch operator panel provides the interface for machine control. Compatible Materials Suitable for forming ABS, PETG, HIPS, PVC, PP, PC, and other thermoplastic sheet materials. Applications Designed for producing packaging trays, plastic enclosures, automotive components, signage, point-of-sale displays, and custom-moulded parts. Suitable for prototyping, small-batch manufacturing, and industrial production.
Specifications
- Machine type
- Sheet-Fed Thermoforming Machine
- Brand
- THERMOFORA
- Title
- Vacuum Forming Machine LITE 1510
- Condition
- New
