TRM-1200x2000

MAAC Model 84R3P is a sheet-fed pressure thermoforming machine with an 8 x 4 ft nominal format (2438.4 x 1219.2 mm) and a three-station rotary layout. It processes cut thermoplastic sheets, with material loading and unloading at the load station. The MAAC R3P rotary pressure-forming platform uses motor-driven platens and an air-cell locking system for pressure forming. The platens extend and lock together before the air cells beneath the floating lower plate are inflated. Multiple control system options are available for this machine family. This listing is for a new machine manufactured to order; final tooling, controls and process options are agreed with MAAC for the application.

MAAC Model C64S is a single-station, sheet-fed thermoforming machine with a 6 x 4 ft nominal format (1828.8 x 1219.2 mm). Part of the MAAC Comet shuttle range, it is designed for forming cut thermoplastic sheets, with loading and unloading at the forming station. The Comet shuttle platform uses Allen-Bradley PLC controls, motor-driven platens and responsive quartz heating. Its single-station arrangement is suited to small- and medium-format thermoforming work. This listing is for a new machine manufactured to order; the final tooling, heating and control configuration is agreed with MAAC for the application.

MAAC Model 85R4DPT is a sheet-fed thermoforming machine with an 8 x 4 ft nominal format (2438.4 x 1219.2 mm), a four-station rotary layout and two ovens. It is configured for twin-sheet pressure forming, joining two heated thermoplastic sheets into a hollow component. The MAAC R4DPT platform supports both single-oven and double-oven twin-sheet processing. Double-oven operation accommodates applications involving thicker materials, inserts or plug assistance. This listing is for a new machine manufactured to order; final tooling, controls and process options are agreed with MAAC for the application.

The LITE 2215 is an industrial vacuum forming machine designed to manufacture large plastic components from thermoplastic sheets. Its robust welded frame and large forming area make it suitable for industrial production and custom manufacturing. Technical Specifications Sheet size: 2240 × 1540 mm Forming area: 2200 × 1500 mm Maximum forming depth: 500 mm Maximum material thickness: 7 mm Power consumption: 90 kW Power supply: Three-phase, 400 V, 50 Hz. Key Features The machine features 450 W infrared quartz heaters, servo-driven movement of the heating unit, and pneumatic drives for both the forming table and clamping frame. A 7-inch operator panel provides access to machine controls and process settings. Compatible Materials Suitable for forming ABS, PETG, HIPS, PVC, PP, PC, and other thermoplastic sheet materials. Applications Designed for producing automotive panels, industrial enclosures, packaging trays, advertising displays, architectural elements, and custom-moulded components. Suitable for prototyping, small-batch manufacturing, and large-format industrial production.
